Accsoon CineView M7 Pro

Accsoon CineView Master 4K - Transmitter onlySKU: WIT07-TX The CineView Master 4K transmitter wirelessly transmits video and audio signals to the CineView Master 4K receiver, as well as to Android and iOS mobile devices via Wi-Fi. The CineView Master 4K's transmitter includes a USB-C Video Out port that can transmit both video and audio signals to iOS devices while simultaneously powering the connected device (5V/3A) via cable connection. Technical dataA/V Processor: 8K High Performance A/V ProcessorProtocol Accsoon Proprietary RTMS 4.0 ProtocolVideo Input: HDMI, 3G SDIVideo Output: HDMI Loop-OutHDMI Loop-out Format: Identical to the HDMI video inputDC Port: 5.5mmx2.1mm, center positiveDC Voltage: 7.4~16.8V Battery: Compatible with NP-F550, NP-F750, NP-F970Audio: 48KHz 16/20/24bitLatency: 1080p < 25ms / 4K < 35ms (Camera latency not included)Transmission Range: ≥ 2.5 km (No obstacles, no interference)OperatingEnvironment Temperature: -10~40°CPower Consumption: 6.5W average *Without powering other devicesDimensions: (Antennas Not Included) 130mm x 95mm x 32 mmWeight: (Antennas Not Included) 322gSDI Input Format1080p: 23.98/24/25/29.97/30/50/59.94/60fps Level A/B1080i: 50/59.94/60i720p: 50/59.94/60pHDMI Input Format4K (3840*2160): 23.98/24/25/29.97/30/50/59.94/60p1080p: 23.98/24/25/29.97/30/50/59.94/60p1080i: 50/59.94/60i720p: 50/59.94/60p

Accsoon CineView Master 4KThe CineView Master 4K - the world's first Tri-Band 4K60 wireless video transmission system for enhanced stability, with 25ms best in class low latency. It redefines wireless video with a fully end-to-end true 4K60 video quality and an extended 2.5km transmission range. With 8K processor and its powerful capabilities, the CineView Master 4K can simultaneously transmit via different streams to meet diverse applications. In addition to SDI/HDMI monitoring, the Accsoon SEE App supports wireless connections on both Android and iOS mo- bile devices, offering professional monitoring features and the capability to upload camera footage to cloud platforms. The newly added MFi-certified wired connection on the transmitter transforms a connected iPad or iPhone into a fully-fledged professional camera-top monitor, significantly enhancing on-site monitoring versatility. One set of wireless transmission that meets diverse needs. FeaturesEnd to End True 4K60 TransmissionTri-band (2.4GHz+5GHz+6GHz) + DFS Wireless Transmission25ms Best in Class Latency2.5km Extended Long Transmission RangeMultiple Video Streams for Diverse ApplicationsTX: SDI Input, HDMI Input, HDMI Loop-outTX: MFi-Certified USB Video Out to iPhone/iPadConvert SDI Input Signal on TX to HDMI Output Signal on RXConvert HDMI Input Signal on TX to SDI Output Signal on RXRX: SDI and HDMI Output SimultaneouslyMonitoring on Up to 5 DevicesMonitoring on Accsoon SEE App8K High Performance A/V ProcessorPowered by DC Input and NP-F BatteryCompatible with Accsoon V-Mount Battery AdapterIntelligent, Quiet Heat DissipationAerospace Grade Aluminum Alloy1.05-inch Full-color LCD Display

Accsoon Cineview SEThe CineView SE is a wireless video transmitter and receiver, with new best in class latency at under 50ms. The CineView SE can transmit a video source via SDI & HDMI up to 1080p 60fps inputs/outputs. It transmits the signal on 2.4GHz+5GHz Dual- Band frequencies simultaneously for increased signal stability and sends video at an impressive maximum range of 1200ft line-of-sight. Transmitter dataVideo Input: SDI/HDMISDI Input Format: 1080p 23.98/24/25/29.97/30/50/59.94/60fpsLevel: A/B 1080p 23.98/24/25/29.97/30/50/59.94/60fpsHDMI Input Format: 1080p 23.98/24/25/29.97/30/50/59.94/60fpsDC Port: 5.5mm x 2.1mm center positiveDC Voltage: 7.4~16.8VAudio: 44.1KHz/48KHz 16bit/24bit PCMLatency: <0.05s (Camera latency not included)OLED Display: 1.3inchTransmission Power: 17~20dBmTransmission Range: 1200ft (No obstacles, no interference)Power Consumption: 4.5Watt (Typical)Operating Environment Temperature: -10°C~40°C℃Dimensions: 105mm x 66mm x 32mm (Antennas not included)Weight: 210g (Antennas not included) Receiver dataVideo Output: SDI/HDMISDI Output Format: 1080p 24/25/30/50/60fps Level AHDMI Output Format: 1080p 24/25/30/50/60fpsDC Port: 5.5mm x 2.1mm center positiveDC Voltage: 7.4~16.8VOLED Display: 1.3inchPower Consumption: 3.5Watt (Typical)Operating Environment Temperature: -10°C~40°C℃Dimensions: 105mm x 66mm x 32mm (Antennas not included)Weight: 210g (Antennas not included)

Accsoon CineView 2 SDIThe Accsoon CineView 2 SDI is a next-generation 1080P wireless video transmission system featuring a massive 1500ft/450m range (line-of-sight). It offers even greater stability than its predecessors and an impressive latency of less than 50ms. The CineView 2 SDI uses the Accsoon Dual-Band transmission technology which takes the same video frame and sends it on both 2.4GHz and 5GHz frequencies at the same time for an inherently more stable wireless connectivity on set FeaturesHigh Reliability 2.4GHz+5GHz Dual-Band Transmission TechnologyExtreme Low Latency of Less Than 50msLong-Range Transmission Range Up to 1500ft/450mSDI & HDMI Input/Output, HDMI Loop-Out, UVC OutSDI to HDMI Pass-throughMonitoring on Up to 4 Devices, Mix and MatchSilent Fanless DesignPower with NP-F battery, DC or 5V 2A USB-C powerMonitoring Made Simple with Accsoon SEE AppAutomatic Channel Selection

Accsoon CineView HEAccsoon CineView HE is an HDMI Dual-Band long range wireless camera transmitter and receiver kit featuring a new USB-C port on receiver for live streaming directly (UVC). It transmits HD video and HQ audio to up to 4 devices (its receiver, mobile phone, iPad, and even MacBook with the newest M1 chip) through Accsoon’s uniquely patent Dual-Band (2.4GHz + 5GHz) transmission technology. And its brand new USB-C port on the receiver will provides creators, live streamers, and podcasters with much more power to display their work or life through live streaming. Transmitter dataVideo Input: HDMIHDMI Input Format: 1080p 23.98/24/25/29.97/30/50/59.94/60fpsHDMI Output Format: 1080p 23.98/24/25/29.97/30/50/59.94/60fpsDC Port: 5.5mm x 2.1mm center positiveDC Voltage: 7.4~16.8V =Audio: 44.1KHz/48KHz 16bit/24bit PCMLatency: <0.06s (Camera latency not included)OLED Display: 1.3inchTransmission Power: 17~20dBmTransmission Range: 1200ft (No obstacles, no interference)Power Consumption: 4.5Watt (Typical)Operating Environment Temperature: -10°C~40°CDimensions: 105mm x 66mm x 32mm (Antennas not included)Weight: 200g (Antennas included) Receiver dataVideo Output: HDMIHDMI Output Format: 1080p 24/25/30/50/60fpsDC Port: 5.5mm x 2.1mm center positiveDC Voltage: 7.4~16.8VOLED Display: 1.3inchPower Consumption: 4.2Watt (Typical)Operating Environment Temperature: -10°C~40°CDimensions: 105mm x 66mm x 32mm (Antennas not included)Weight: 200g (Antennas included)
