Wooden Camera Quick Back v2 SKU: 159400 New design and lower package price of Wooden Camera Quick Back v2 allows mounting of all three styles of battery plates without intermediary adapters. Anton Bauer QRC, Switronix, RED, Blueshape, IDX, and more will mount directly. Attaches to back of any RED Module without tools. Combine with battery plate for compact power solution. Use with Wooden Camera A-Lock to mount the battery plate in alternative configurations. The Quick Back v2 system is the only battery solution that can natively attach to the back of any RED Module, including the +1 Module!* Install M4 screws before attaching heavy batteries Quick Back v2 Includes 4 x m4x12mm socket cap6 x m3x5mm socket screws4 x m3x6mm phillips screws4 x m3x12mm phillips screws4 x m3x14mm phillips screws

Wooden Camera Quick Back (RED DSMC2) SKU: 214000 The new Quick Back (Weapon) allows for any standard V-Mount plate or Gold Mount plate to be attached directly to the back of the RED Weapon camera or to the back of the Base Expander and REDvolt Expander without tools! Simply turn the four knurled thumbscrews to lock it into place. The Quick Back (Weapon) is designed to be compatible with Wooden Camera's previous battery plates for Epic and Scarlet like the WC V-Mount (Epic/Scarlet) and WC Gold Mount (Epic/Scarlet) which will help users transition from one camera to the next. Wooden Camera will also be offering a cable-less WC V-Mount (Weapon) and WC Gold Mount (Weapon) that provides power to the camera via the 13 pin pogo connector on the back. This will be available as a user installable upgrade. Regarding configuration of the device, V-Mount plates can be attached in two different ways by repositioning the smaller component. The "low" mode places the battery plate even with the top of the camera body. The "high" mode places the battery plate even with the bottom of the back face of the camera. For Gold Mount plates, there are three options. The same "high" and "low" modes but also a "middle" configuration where the smaller component is not used at all. Note that what is shown in the photos are prototypes but the final version will look almost identical. The pogo pin versions are shown for illustration purposes and are subject to change. Includes 4 x m3x5mm socket screws4 x  m3x8mm phillips screws4 x m3x12mm phillips screws

Wooden Camera Gimbal Battery Bracket Only (Weapon/Scarlet-W/Raven) SKU: 221000 Gimbal Battery Bracket (Weapon/Scarlet-W/Raven) attaches directly to the side of the RED Weapon, Scarlet Weapon, or Raven camera using four M3 captured screws and provides mounting points for standard V-Mount and Gold Mount battery plates. The red colored lever allows the record and power button to remain functional while the bracket is installed. This product is ideal for use with the RED Base Expander Module, Jetpack, and upcoming Wooden Camera power module where the standard DSMC LEMO power input is present. V-Mount and Gold Mount plates can be attached in many ways, all of which are engraved onto the product itself. This includes positions right side up, upside down, sideways, etc. Wooden Camera Gimbal Battery Bracket is recommended to use with this product are the WC V-Mount (Epic/Scarlet), WC Gold Mount (Epic/Scarlet), and Power Extension Cables. Gimbal Bracket Includes 4 x m3x8mm phillips screws4 x m3x12mm phillips screws Gimbal Battery Bracket Specifications Weight 90.7 gDimensions 25.4 mm x 101.6 mm x 177.8 mm

Wooden Camera Battery Swing SKU: 245700 Wooden Camera Battery Swing provides standard V-Mount and Gold Mount hole patterns for mounting WC battery plates and the D-Box (Alexa Mini). Quickly access the back of the camera by pulling the black pin and swinging open. Mounting bracket has integrated 15mm rod openings and is most commonly used in the lower position for bottom rods. Battery Swing can be mounted to top rods by moving the swing arm to the top row of holes on the battery bracket. Includes 4 x M3 x 12mm Pan Head Screws 4 x M3 x 8mm Pan Head Screws 4 x M3 x 8mm Phillips Flat Head Screws (for attaching D-Box if original screws were lost) Specifications Weight: 226.80g Dimensions: 152.4 x 114.3 x 45.7 mm

Wooden Camera C-Box (Converter, D-Tap) SKU: 176200 C-Box (Converter, D-Tap) accepts HDMI and 3G HD-SDI input, selectable via switch on operator's side, and outputs simultaneously three channels of HD-SDI and two of HDMI. The device draws power from the D-Tap of a battery or battery plate using the included cable. Each video output is independently reclocked and carries the same signal strength as the original. LED indicators are located on the operator's side to show status of power and signal. This version attaches between any V-Mount or QRC-style Gold Mount and wherever the plate was attached previously. For example, the Wooden Camera C-Box (Converter, D-Tap) can fit between the WC V-Mount (Epic/Scarlet) and the Quick Back v2. Another example would be attaching it between the WC Gold Mount (BMC) and the Battery Slide. C-Box Overview Power Input 4 pin mini-XLR, 12-24 VDC .5AIncluded 4" D-Tap to 4 pin mini-XLR cableLED indicator for Signal and Power on operator sideBolts to standard V-Mount, QRC-style Gold Mount, and RED/Blueshape mounting patternsStandard V-Mount, QRC-style Gold Mount, and RED/Blueshape plates can be bolted to the box itself1/4-20 holes on bottom allow for attachment of rod clamps, cheeseplates, and other accessoriesRe-clocks standard SD, HD and 3G SDI data ratesAuto bypasses non-standard SDI rates from 20Mbit/s to 3Gbit/sPasses SDI embedded audio and ancillary dataOperating Temperature 0 to +40 COperating Humidity 0 to 90% Non-Condensing Signal Information Data Types: SMPTE 259/292/424Data Rates: 19 Mbit/s through 3.0 Gbit/sRe-clocking Data Rates: 270 Mbit/s, 1.485 Gbit/s, 2.97 Gbit/sInput/Output Return Loss: > 15dB @ HD, > 12dB @ 3GInput Level: 800 mV P-P +/- 20%Input Impedance: 75 Ohms +/- 1%Output Level: 800 mV P-P +/- 5%Output Impedance: 75 Ohms +/- 1%Output Jitter: < 0.2 UI Other Notes A/C Adapter included2 positions available for mounting QRC-style power plates: high and lowHole pattern available for mounting common accessory V mount4 pin mini-XLR power connector same as TV Logic/Alphatron
