Blackmagic ATEM 1 M/E Advanced Panel The new Blackmagic ATEM 1 M/E Advanced Panel is an elegantly designed professional hardware control panel for all ATEM switchers. It combines modern design with the latest broadcast technology for faster workflows. The new design features a built in LCD and high quality curved buttons that help reduce incorrect key presses. The buttons also have color backlighting to help you quickly recognize important keys. You also get a professional joystick for DVE and camera adjustments, smooth weighted t-bar fader and much more. The buttons feature dynamic displays that allow full customization of the labels as well as custom colors. The shift buttons allow you to double up the number of inputs by selecting a second set of shifted source buttons so you can control up to 20 inputs. The compact size and durable design of the ATEM 1 M/E Advanced Panel fits in a standard equipment rack, making it perfect for shelf mounting in broadcast trucks, mobile racks and fly away kits.

Blackmagic ATEM 1 M/E Advanced Panel 20 SKU: SWPANELADV1ME20 The ATEM 1 M/E Advanced Panel 20 is a single M/E, 20 input button switching panel that includes the features and flexibility needed for switching big and small productions in a highly portable and compact design. It has 2 independent system control LCDs plus it can control up to 4 M/Es in larger switchers. All input buttons include LCDs for custom labeling and there is an independent select bus. Dual power inputs provide redundancy and the built-in 4 port Ethernet switch means no additional network equipment is needed so it will fit even the most challenging live production spaces! Connections Ethernet: 4 x 10/100/1000 BASE-T with loop output for additional control panels or computersSoftware Updates: 1 x USB-C for firmware updates. Merkmale Number of Mix Effects Rows: 1Direct Cross Points: 20Shifted Cross Points: 40Crosspoint Button Type: Tri-Color LEDPreview Transition: 1Transition Rate Displays: Via main menuLCD Menu Displays: 2Menu Control: 2 x 20 buttonsDedicated Macro Buttons: 1 x 20Transport Control Buttons: 8Destination Bus: 1Source Select Bus: 1Fader Bar: 13 Axis Joystick: 1Numeric Keypad: 1

Blackmagic ATEM 1 M/E Advanced Panel 30 SKU: SWPANELADV1ME30 The ATEM 1 M/E Advanced Panel 30 features a single M/E row, 30 input button design that is ideal for switching big productions from desk surfaces that are not deep enough for a bigger panel. It has 3 independent system control LCDs plus it can control up to 4 M/Es in larger switchers. All input buttons include LCDs for custom labeling and it also includes an independent select bus! Dual power inputs provide redundancy and the built-in 4 port Ethernet switch means no additional network equipment is needed so it will fit even the most challenging live production spaces! Connections Ethernet: 4 x 10/100/1000 BASE-T with loop output for additional control panels or computersSoftware Updates: 1 x USB-C for firmware updates. Features Number of Mix Effects Rows: 1Direct Cross Points: 30Shifted Cross Points: 60Crosspoint Button Type: Tri-Color LEDPreview Transition: 1Transition Rate Displays: Via main menuLCD Menu Displays: 3Menu Control: 3 x 20 buttonsDedicated Macro Buttons: 1 x 30Transport Control Buttons: 8Destination Bus: 1Source Select Bus: 1Fader Bar: 13 Axis Joystick: 1Numeric Keypad: 1

Blackmagic ATEM 2 M/E Advanced Panel 20SKU: BM-SWPANELADV2ME20 The ATEM 2 M/E Advanced Panel 20 by Blackmagic Design offers two M/E rows, each with 20 input buttons and a separate system control LCD in each row. Additionally, each row can control up to four larger switchers. Both rows and all input buttons feature integrated LCDs for custom labels. Furthermore, each row has its own selection bus.ConnectionsEthernet: 4 x 10/100/1000 BaseT with loop output for additional control panels or computersSoftware Updates: 1 USB-C for firmware updatesFeaturesNumber of Mix/Effect Blocks: 2Direct Crosspoints: 20Auxiliary Crosspoints: 40Crosspoint Button Type: Tri-color LEDCrosspoint Label: LCD with 6 lines of 24 characters eachNext Transition Selectors: 2 BKG, Keyer Buttons 1-4On-Air Indicators: 8Power Status Indicators: NoneDSK Transition Selectors: Auto, Cut, Tie/Preview x 2Transition Preview: 2Transition Rate Indicators: Via main menuLCD Menu Displays: 2Menu Control: 2 x 20 buttonsDedicated Macro Buttons: 2 x 20Transport Control Buttons: 8Destination Bus: 2Source Selection Bus: 2Fader Bars: 23-Axis Joystick: 1Numeric Keypad: 1Software Applications: ATEM Software Control PanelOperating SystemsMac 10.14 Mojave, Mac 10.15 Catalina, or higherWindows 10, 64 BitPower RequirementsInput Voltage: 2 integrated AC power supplies for 110–240 VRedundant Power: YesPower Consumption: 150 WPhysical SpecificationsDimensions: 725 x 485 x 166 mmWeight: 11 kgEnvironmentOperating Temperature: 0-40 °CStorage Temperature: -20-60 °CRelative Humidity: Up to 95 %

Blackmagic ATEM 2 M/E Advanced Panel 30SKU: BM-SWPANELADV2ME30The ATEM 2 M/E model by Blackmagic Design offers two M/E rows, each with 30 input buttons and a separate system control LCD in each row. Additionally, each row can control up to four larger mixer M/Es. Both rows and all input buttons feature integrated LCDs for custom labels. Furthermore, each row has its own selection bus.ConnectionsEthernet: 4 x 10/100/1000 BASE-T with loop output for additional control panels or computersSoftware Updates: 1 USB-C for firmware updatesFeaturesNumber of Mix/Effect Blocks: 2Direct Crosspoints: 30Offset Crosspoints: 60Crosspoint Button Type: Tri-color LED indicationCrosspoint Label: LCD with 6 lines of 24 characters eachOn-Air Indicators: 12Power Status Indicators: NoneDSK Transition Selectors: 4x Auto, Cut, Tie/PreviewTransition Preview: 2Transition Rate Indicators: via main menuLCD Menu Displays: 3Menu Control: 3x 20 buttonsDedicated Macro Buttons: 2x 30Transport Control Buttons: 8Destination Bus: 2Source Select Bus: 2Transition Lever: 23-Axis Joystick: 1Numeric Keypad: 1

Blackmagic ATEM Micro PanelThe ATEM Micro Panel is a low cost solution for adding panel control to ATEM Software control. Featuring the same high end buttons as ATEM Advanced Panels you get a true broadcast quality feel. It also has a familiar layout with buttons for program and preview. You can use the shift buttons to access up to 20 sources. There are 4 upstream and 2 downstream key buttons, plus a macro button. It even has 4 M/E buttons so you can control a massive 4 M/E switcher! There’s a fader for smooth manual transition control, which also means it’s low profile and very portable. With connection via USB-C or Bluetooth and a large internal battery, Blackmagic ATEM Micro Panel is perfect when you need a portable panel! Number of Mix Effects Rows: 1Direct Cross Points: 10Shifted Cross Points: 20Crosspoint Button Type: Tri-Color LEDPreview Transition: 1Switching Type Buttons: CUT and AUTOTransition Type Buttons: DIP, DVE, STINGER, MIX, WIPEM/E Select Buttons: 4Upstream Key Buttons: 4 with ON/OFFDownstream Key Buttons: 2 with ON/OFFTransition Slider: 1Power Supply: Internal battery with power switch / USB-C port for external power supply and battery chargingPower Usage: 3 W max

Kiloview Link Deck SeriesThe Kiloview LinkDeck Series consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck, and can control all aspects of Kiloview hardware and software based on RTC technology. LinkDeck enables users to manage the whole Kiloview ecosystem including NDI ONAIR / NDI CORE*/ NDI RECORDER* / NDI Encoder / NDI Decoder / Multiview / KiloLink Server*.By developing a 3rd-party plug-in based on Python, Linkdeck even allows interaction with systems like TriCaster and vMix.LinkDeck is an IP-based solution that delivers safe and stable transmission. All the control and management for the system is controlled by one PoE cable.Kiloview LinkDeck consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck. Each deck can be combined to your own specification to create an exclusive workbench with fully customised content. This unique design also offers easy assembly and installation for an optimised user experience.Panel DeckPanel Deck is made of robust aircraft-grade materials and designed for bringing the studio experience to you, wherever you are with its own whole set of pro-level joystick/buttons/switches/selectors and ports.The Panel Deck, equipped with a 10.1” touch screen and a bi-color LED keyboard, provides the easy operation and an intuitive user experience. The 10.1” screen allows you to customize whatever product you want to control. Both soft keys and physical keys control all aspects of your workflow, with DC and PoE providing the power source to your entire suite of Decks.TAKE DeckTake Deck helps you to switch like a pro with a “T” stick and dual LED displays. 12 buttons are available to control Switching / FTB / Recording / Live streaming / Lock screen with one single press, making every step of the process easy to operate.PTZ DeckThe PTZ Deck offers single handed control of all your PTZ cameras, with the simple movement of the joystick and switches to adjust focus, aperture and white balance.ZOOM DeckWith Zoom Deck’s rocker, you can simply zoom in / out whenever you want. It also has 11 soft buttons for all your personal customization. Technical dataPanel Deck DP-01Display: 10.1" multi touch LCD screenResolution: 1920 x 1200Keyboard: 24 keys（Bi-color tally)CPU: 8-core CPUMemory: 2GBStorage: 16GBVideo Output: 1 x HDMIInternet: 1GbE port with PoEPower Supply: DC5.5/2.5 12VOutput Resolutions: Up to 1080P60Key: 24, user-defined keysUSB Port: 7×Type-C 2.0DC Port: Single DC5.5/2.1Weight: 3,01kgDimension: 285.33*260.00*110.10mmOperating Temperature: -20°C~45°CPTZ Deck DQ-01USB: 2 * USB Type -C 2.0Key: 1Control Knob: 3Joystick: 1Tally: 3（2 in white，1 in RGB based on settings)Dimension: 260.00*130.00*107.45mmWeight: 1,49 kgZoom Deck DZ-01Keys: 13ZOOM Rocker: 1USB: 2 * Type-C 2.0Dimension: 260.00*130.00*53.68mmWeight: 1,38 kgTake Deck DT-01USB: 2 * Type-C 2.0Keys: 13T Stick: 1Dimension: 260.00*130.00*74.00mmWeight: 1,46 kg

Kiloview Link Deck SeriesThe Kiloview LinkDeck Series consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck, and can control all aspects of Kiloview hardware and software based on RTC technology. LinkDeck enables users to manage the whole Kiloview ecosystem including NDI ONAIR / NDI CORE*/ NDI RECORDER* / NDI Encoder / NDI Decoder / Multiview / KiloLink Server*.By developing a 3rd-party plug-in based on Python, Linkdeck even allows interaction with systems like TriCaster and vMix.LinkDeck is an IP-based solution that delivers safe and stable transmission. All the control and management for the system is controlled by one PoE cable.Kiloview LinkDeck consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck. Each deck can be combined to your own specification to create an exclusive workbench with fully customised content. This unique design also offers easy assembly and installation for an optimised user experience.Panel DeckPanel Deck is made of robust aircraft-grade materials and designed for bringing the studio experience to you, wherever you are with its own whole set of pro-level joystick/buttons/switches/selectors and ports.The Panel Deck, equipped with a 10.1” touch screen and a bi-color LED keyboard, provides the easy operation and an intuitive user experience. The 10.1” screen allows you to customize whatever product you want to control. Both soft keys and physical keys control all aspects of your workflow, with DC and PoE providing the power source to your entire suite of Decks.TAKE DeckTake Deck helps you to switch like a pro with a “T” stick and dual LED displays. 12 buttons are available to control Switching / FTB / Recording / Live streaming / Lock screen with one single press, making every step of the process easy to operate.PTZ DeckThe PTZ Deck offers single handed control of all your PTZ cameras, with the simple movement of the joystick and switches to adjust focus, aperture and white balance.ZOOM DeckWith Zoom Deck’s rocker, you can simply zoom in / out whenever you want. It also has 11 soft buttons for all your personal customization. Technical dataPanel Deck DP-01Display: 10.1" multi touch LCD screenResolution: 1920 x 1200Keyboard: 24 keys（Bi-color tally)CPU: 8-core CPUMemory: 2GBStorage: 16GBVideo Output: 1 x HDMIInternet: 1GbE port with PoEPower Supply: DC5.5/2.5 12VOutput Resolutions: Up to 1080P60Key: 24, user-defined keysUSB Port: 7×Type-C 2.0DC Port: Single DC5.5/2.1Weight: 3,01kgDimension: 285.33*260.00*110.10mmOperating Temperature: -20°C~45°CPTZ Deck DQ-01USB: 2 * USB Type -C 2.0Key: 1Control Knob: 3Joystick: 1Tally: 3（2 in white，1 in RGB based on settings)Dimension: 260.00*130.00*107.45mmWeight: 1,49 kgZoom Deck DZ-01Keys: 13ZOOM Rocker: 1USB: 2 * Type-C 2.0Dimension: 260.00*130.00*53.68mmWeight: 1,38 kgTake Deck DT-01USB: 2 * Type-C 2.0Keys: 13T Stick: 1Dimension: 260.00*130.00*74.00mmWeight: 1,46 kg

Kiloview Link Deck SeriesThe Kiloview LinkDeck Series consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck, and can control all aspects of Kiloview hardware and software based on RTC technology. LinkDeck enables users to manage the whole Kiloview ecosystem including NDI ONAIR / NDI CORE*/ NDI RECORDER* / NDI Encoder / NDI Decoder / Multiview / KiloLink Server*.By developing a 3rd-party plug-in based on Python, Linkdeck even allows interaction with systems like TriCaster and vMix.LinkDeck is an IP-based solution that delivers safe and stable transmission. All the control and management for the system is controlled by one PoE cable.Kiloview LinkDeck consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck. Each deck can be combined to your own specification to create an exclusive workbench with fully customised content. This unique design also offers easy assembly and installation for an optimised user experience.Panel DeckPanel Deck is made of robust aircraft-grade materials and designed for bringing the studio experience to you, wherever you are with its own whole set of pro-level joystick/buttons/switches/selectors and ports.The Panel Deck, equipped with a 10.1” touch screen and a bi-color LED keyboard, provides the easy operation and an intuitive user experience. The 10.1” screen allows you to customize whatever product you want to control. Both soft keys and physical keys control all aspects of your workflow, with DC and PoE providing the power source to your entire suite of Decks.TAKE DeckTake Deck helps you to switch like a pro with a “T” stick and dual LED displays. 12 buttons are available to control Switching / FTB / Recording / Live streaming / Lock screen with one single press, making every step of the process easy to operate.PTZ DeckThe PTZ Deck offers single handed control of all your PTZ cameras, with the simple movement of the joystick and switches to adjust focus, aperture and white balance.ZOOM DeckWith Zoom Deck’s rocker, you can simply zoom in / out whenever you want. It also has 11 soft buttons for all your personal customization. Technical dataPanel Deck DP-01Display: 10.1" multi touch LCD screenResolution: 1920 x 1200Keyboard: 24 keys（Bi-color tally)CPU: 8-core CPUMemory: 2GBStorage: 16GBVideo Output: 1 x HDMIInternet: 1GbE port with PoEPower Supply: DC5.5/2.5 12VOutput Resolutions: Up to 1080P60Key: 24, user-defined keysUSB Port: 7×Type-C 2.0DC Port: Single DC5.5/2.1Weight: 3,01kgDimension: 285.33*260.00*110.10mmOperating Temperature: -20°C~45°CPTZ Deck DQ-01USB: 2 * USB Type -C 2.0Key: 1Control Knob: 3Joystick: 1Tally: 3（2 in white，1 in RGB based on settings)Dimension: 260.00*130.00*107.45mmWeight: 1,49 kgZoom Deck DZ-01Keys: 13ZOOM Rocker: 1USB: 2 * Type-C 2.0Dimension: 260.00*130.00*53.68mmWeight: 1,38 kgTake Deck DT-01USB: 2 * Type-C 2.0Keys: 13T Stick: 1Dimension: 260.00*130.00*74.00mmWeight: 1,46 kg

Kiloview Link Deck SeriesThe Kiloview LinkDeck Series consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck, and can control all aspects of Kiloview hardware and software based on RTC technology. LinkDeck enables users to manage the whole Kiloview ecosystem including NDI ONAIR / NDI CORE*/ NDI RECORDER* / NDI Encoder / NDI Decoder / Multiview / KiloLink Server*.By developing a 3rd-party plug-in based on Python, Linkdeck even allows interaction with systems like TriCaster and vMix.LinkDeck is an IP-based solution that delivers safe and stable transmission. All the control and management for the system is controlled by one PoE cable.Kiloview LinkDeck consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck. Each deck can be combined to your own specification to create an exclusive workbench with fully customised content. This unique design also offers easy assembly and installation for an optimised user experience.Panel DeckPanel Deck is made of robust aircraft-grade materials and designed for bringing the studio experience to you, wherever you are with its own whole set of pro-level joystick/buttons/switches/selectors and ports.The Panel Deck, equipped with a 10.1” touch screen and a bi-color LED keyboard, provides the easy operation and an intuitive user experience. The 10.1” screen allows you to customize whatever product you want to control. Both soft keys and physical keys control all aspects of your workflow, with DC and PoE providing the power source to your entire suite of Decks.TAKE DeckTake Deck helps you to switch like a pro with a “T” stick and dual LED displays. 12 buttons are available to control Switching / FTB / Recording / Live streaming / Lock screen with one single press, making every step of the process easy to operate.PTZ DeckThe PTZ Deck offers single handed control of all your PTZ cameras, with the simple movement of the joystick and switches to adjust focus, aperture and white balance.ZOOM DeckWith Zoom Deck’s rocker, you can simply zoom in / out whenever you want. It also has 11 soft buttons for all your personal customization. Technical dataPanel Deck DP-01Display: 10.1" multi touch LCD screenResolution: 1920 x 1200Keyboard: 24 keys（Bi-color tally)CPU: 8-core CPUMemory: 2GBStorage: 16GBVideo Output: 1 x HDMIInternet: 1GbE port with PoEPower Supply: DC5.5/2.5 12VOutput Resolutions: Up to 1080P60Key: 24, user-defined keysUSB Port: 7×Type-C 2.0DC Port: Single DC5.5/2.1Weight: 3,01kgDimension: 285.33*260.00*110.10mmOperating Temperature: -20°C~45°CPTZ Deck DQ-01USB: 2 * USB Type -C 2.0Key: 1Control Knob: 3Joystick: 1Tally: 3（2 in white，1 in RGB based on settings)Dimension: 260.00*130.00*107.45mmWeight: 1,49 kgZoom Deck DZ-01Keys: 13ZOOM Rocker: 1USB: 2 * Type-C 2.0Dimension: 260.00*130.00*53.68mmWeight: 1,38 kgTake Deck DT-01USB: 2 * Type-C 2.0Keys: 13T Stick: 1Dimension: 260.00*130.00*74.00mmWeight: 1,46 kg

Kiloview Link Deck SeriesThe Kiloview LinkDeck Series consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck, and can control all aspects of Kiloview hardware and software based on RTC technology. LinkDeck enables users to manage the whole Kiloview ecosystem including NDI ONAIR / NDI CORE*/ NDI RECORDER* / NDI Encoder / NDI Decoder / Multiview / KiloLink Server*.By developing a 3rd-party plug-in based on Python, Linkdeck even allows interaction with systems like TriCaster and vMix.LinkDeck is an IP-based solution that delivers safe and stable transmission. All the control and management for the system is controlled by one PoE cable.Kiloview LinkDeck consists of four unique design decks including Panel Deck, Take Deck, Zoom deck and the PTZ Deck. Each deck can be combined to your own specification to create an exclusive workbench with fully customised content. This unique design also offers easy assembly and installation for an optimised user experience.Panel DeckPanel Deck is made of robust aircraft-grade materials and designed for bringing the studio experience to you, wherever you are with its own whole set of pro-level joystick/buttons/switches/selectors and ports.The Panel Deck, equipped with a 10.1” touch screen and a bi-color LED keyboard, provides the easy operation and an intuitive user experience. The 10.1” screen allows you to customize whatever product you want to control. Both soft keys and physical keys control all aspects of your workflow, with DC and PoE providing the power source to your entire suite of Decks.TAKE DeckTake Deck helps you to switch like a pro with a “T” stick and dual LED displays. 12 buttons are available to control Switching / FTB / Recording / Live streaming / Lock screen with one single press, making every step of the process easy to operate.PTZ DeckThe PTZ Deck offers single handed control of all your PTZ cameras, with the simple movement of the joystick and switches to adjust focus, aperture and white balance.ZOOM DeckWith Zoom Deck’s rocker, you can simply zoom in / out whenever you want. It also has 11 soft buttons for all your personal customization. Technical dataPanel Deck DP-01Display: 10.1" multi touch LCD screenResolution: 1920 x 1200Keyboard: 24 keys（Bi-color tally)CPU: 8-core CPUMemory: 2GBStorage: 16GBVideo Output: 1 x HDMIInternet: 1GbE port with PoEPower Supply: DC5.5/2.5 12VOutput Resolutions: Up to 1080P60Key: 24, user-defined keysUSB Port: 7×Type-C 2.0DC Port: Single DC5.5/2.1Weight: 3,01kgDimension: 285.33*260.00*110.10mmOperating Temperature: -20°C~45°CPTZ Deck DQ-01USB: 2 * USB Type -C 2.0Key: 1Control Knob: 3Joystick: 1Tally: 3（2 in white，1 in RGB based on settings)Dimension: 260.00*130.00*107.45mmWeight: 1,49 kgZoom Deck DZ-01Keys: 13ZOOM Rocker: 1USB: 2 * Type-C 2.0Dimension: 260.00*130.00*53.68mmWeight: 1,38 kgTake Deck DT-01USB: 2 * Type-C 2.0Keys: 13T Stick: 1Dimension: 260.00*130.00*74.00mmWeight: 1,46 kg
