Hollyland Pyro 7 wireless monitor
Product number:
SW28207.1
Manufacturer:
Hollyland
Manufacturer product number:
Pyro 7
Delivery time:
1-3 days
Hollyland Pyro 7
Hollyland Pyro 7 is a 7-inch wireless monitor that integrates the functionalities of TX, RX, and monitor, all in one. It utilizes Auto Dual-Band Hopping (ADH) technology. With 1,300ft (400m) and an incredibly low latency of only 60ms, Pyro 7 supports 2.4GHz/5GHz dual-band transmission and automatic frequency hopping. Its exceptional hardware design enables Pyro 7 to simultaneously connect one transmitter to four receivers, and the convenience of dual-camera monitoring is achieved through customizable shortcut keys. Additionally, the upgraded HollyOS system provides enhanced image analysis capabilities and allows for video file export via an external SD card. Pyro 7 is compatible with Pyro H and Pyro S, which means you can easily pair Pyro 7 with either Pyro H or Pyro S. This provides you with greater flexibility and scalability to meet various monitoring needs.
FEATURES
- 1TX & 4RX
- 1300ft (400m) & 0.06s Latency
- 2.4GHz & 5GHz Dual Band
- Auto Frequency Hopping
- TX, RX, and Monitor – All in One
- Dual-View Quick Monitoring Switch
- 7 Inch & 1200 nits
- Precise Image Analysis (icon HollyOS)
- SDI & HDMI Loopout
- RTMP Streaming
Technical data
- Input port: HDMI 1.4b + 3G SDI
- Outout port: HDMI 1.4b + 3G SDI
- Antenna: RP-SMA Malex2
- Power input: DC Input (2.0mm core socket)
- Headphone Jack: 3.5mm
- Screen Resolution: 1920 × 1200 pixels
- Pixel Density: 323 PPI
- Aspect ratio: 16:9
- Screen Brightness: 1200 nits
- Screen size: 7-inch touchscreen
- Contrast ratio: 1000:1
- Power consumption: < 22W
- Audio format: HDMI 1.4b 8-Channel
- Bandwidth: 20 MHz; 40 MHz (in Broadcast mode)
- Transmission latency: ≈ 60ms (test data when 1080p60 signals are transmitted in a laboratory)
- Transmit Power: ≤ 23 dBm
- Receiver Sensitivity: -80 dBm
- Display Latency:< 50ms
Details of the manufacturer
- Shenzhen Hollyland Technology Co.,Ltd
- 8F, Building 5#D, Skyworth Innovation Valley, Tangtou Road Shiyan Street, Baoan District, Shenzhen, China
(852) 3666 5111
Details of the person responsible for putting the product on the European market
- Hollyland Europe GmbH
- Ingolstädter Str. 20
- 80807, Munich, Germany
+49 89 13957785
Warnings and safety information
