Datavideo DAC-60 SD/HD/3G-SDI to VGA Scaler and Converter
€390.00
Datavideo DAC-60
The Datavideo DAC-60 is a HD/SD-SDI to VGA converter. It's designed for use with equipment such as projectors, plasma TV, and LCD screens. The DAC-60 is compatible with NTSC/PAL SD signals, as well as HD-SDI and 3G SDI signals. The unit will automatically detect scale and convert the input video signals into VGA compatible signals for display on VGA-based equipment.
Features
- Supports Brightness, Contrast, Hue and Saturation of Adjustment
- Supplied with a Windows application that connects via USB and enables adjustment of the colour, contrast or saturation
- Settings from the application are retained when the computer and power are removed
- SDI loop through is unaffected by the adjustments to the VGA signal
- Dual output available (SDI & VGA)
- Auto 3G/HD/SD-SDI detection
VGA Output formats
- T800 x 600
- 1024 x 768
- 1280 x 800
- 1280 x 1024
- 1366 x 768
- 1400 x 1050
- 1600 x 1200
- 1920 x 1080
- 1920 x 1200
Supports 3G/HD/SD-SDI format
- TSD - 720 x 480 i / 720 x 576 i
- HD - 1280 x 720 50p/60p/59.94p
- 1920 x 1080 50i/60i/59.94i
- 1920 x 1080 24p/25p/30p
- 3G - 1920 x 1080 50p/60p/59.94p Support 525i & 625i SD D1 format
In the box
- 1 x DAC-60 product
- 1 x AD Switch DC 12V
Details of the manufacturer
- Datavideo Technologies Co. Ltd – Taiwan
- 10F. No. 176, Jian 1st Road Zhonghe Dist. New Taipei City 235, Taiwan
+886-2-8227-2888
Details of the person responsible for putting the product on the European market
- Datavideo Technologies Europe B.V.
- Floridadreef 106
- 3565 AM UTRECHT, The Netherlands
+31 30 261 9656
