BirdDog Flex 4K BACKPACK

BirdDog 4K QUAD Four channel 12G SDI to 4Kp60 NDI Encoder/Decoder Following on from the award winning HD NDI® products, the 4K Family has been engineered from the ground up for real-world users. Built around BirdDog’s custom NDI® silicon chip and housed in an aircraft grade aluminium case, features include 12G SDI and HDMI 2.0 inputs and outputs, built-in cross converter, SFP+ port for 10GbE connectivity, active loop outs, audio intercom system, NDI® tally system, PoE, and compatibility with BirdDog’s Comms Pro and Central Pro apps. Features 4K NDI FamilyEncode & Decode up to 4Kp6012G & HDMI 2.0 connectionsBuilt-in cross converterSFP+ port for 10GbE connectivityActive loop outs Three models to choose from 4K HDMI1x HDMI 2.0 Input1x HDMI 2.0 Output1x 12G Output4K 12G SDI1x HDMI 2.0 Output1x 12G SDI Output1x 12G SDI Output4K QUAD1x HDMI 2.0 Output4x 12G SDI Input/Output

BirdDog 4K 12G SDI 12G SDI NDI Encoder/Decoder With support for all resolutions up to 4Kp60, including all HD resolutions, Encoding and Decoding 4K Full NDI® has never been easier. All SDI connectors on the 4K line are 12G SDI, including all four SDI connectors on 4K Quad. All the HDMI connectors are 2.0 for maximum compatibility with your sources and destinations. Industry standard SFP+ connection allows for short, medium, and long range connections over fiber and supports Ethernet protocols from 1GbE to 10GbE. A full Tally system is built right into the 4K Family and it requires zero configuration. Includes a built-in large Tally light for your on-air talent to easily see which camera is live, plus user selectable Tally borders on loop out. All 4K products include a built in cross converter and of the 12G SDI inputs can be looped out the HDMI 2.0 port and any of the HDMI 2.0 inputs can be looped out the 12G SDI. With the optional USB to Ethernet dongle you can control any PTZ camera that supports NDI®, NDI|HX, or Visca over IP. Full NDI® is a variable bit rate codec. In normal circumstances BirdDog recommends allowing around 140Mbps in HD, or 6 streams per 1GbE cable with some headroom. In 4K it is recommended to allow around 300Mbps or 3 streams with some headroom to allow for any unforeseen spikes. With BirdDog’s tools you can select the bit rate to suit your bandwidth and requirements. In both HD you can slide between 80-180Mbps and in 4K you can select the data rate to be anywhere between 60 and 360Mbps. 4K Family include free Audio Intercom software, Comms Lite. Comms Lite supports four BirdDog devices and one Director. Need a more powerful Audio Intercom solution? Comms Pro gives you all the amazing features of Comms Lite plus allows you create you up to five groups, adds additional push to talk buttons for the director, ability to change groups on the fly, plus more. BirdDog Central is a software platform set to redefine the way we think about driving content to TV screens. By teaming up Central with any NDI® source, including all BirdDog hardware capable of creating NDI® sources, you can now drive your NDI® streams to any BirdDog Studio NDI, Mini or 4K Family to decode NDI® back to SDI or HDMI.

BirdDog Flex 4K OUT BirdDog Flex 4K OUT is 4K Full NDI Encoder with Tally, Comms, PTZ Control, PoE+, and DC Power Output Flex delivers everything you have come to expect from BirdDog’s one cable solution including Tally, Audio Intercom, Video, Audio, PTZ Control, and Power all down a single Ethernet cable. With 3 models to choose from in the Flex Family is a Flex to perfect for your workflow needs. Full NDI® is a variable bit rate codec. In normal circumstances BirdDog recommends allowing around 140Mbps in HD, or 6 streams per 1GbE cable with some headroom. In 4K it is recommended to allow around 300Mbps or 3 streams with some headroom to allow for any unforeseen spikes.

BirdDog 4K HDMI HDMI 2.0, 4Kp60 NDI Encoder/Decoder Bi-directional 4K NDI to HDMI scaling converter with HDMI pass through and 12G-SDI out. Highlights Encode & Decode up to 4Kp6012G & HDMI 2.0 connectionsSFP+ for 10GbE & long rangeNDI Tally that just worksCross ConverterPTZ ControlAdaptive bit rate. Slide your way to gloryFree Comms Lite. Upgrade to Comms ProDistribute NDI® content everywhere. Just add Central

BirdDog Flex 4K IN BirdDog Flex 4K IN is 4K Full NDI Encoder with Tally, Comms, PTZ Control, PoE+, and DC Power Output BirdDog’s revolutionary Studio NDI gave the world NDI, Power, Video, Audio, Tally, and Audio Intercom all done a single Ethernet cable. Flex 4K IN take it one step even further and provides an additional 15w power allowing you to use the DC output to power your monitor, recorder, or even your camera. Flex’s revolutionary Halo Tally system is built right into the Flex Family and requires zero configuration when connected with any NDI enabled, software based, production system. The Halo Tally is designed to be seen by the camera operators as well as the on air talent.
