AVMatrix SHARK S8X 8‑channel SDI/HDMI switcher
AVMatrix Shark S8X
AVMatrix Shark S8X – 8-Channel SDI/HDMI Live Production Switcher: 6×3G-SDI + 2×4K HDMI inputs, flexible multi-view routing, AUX (playback/UVC/NDI), 6×PGM outputs, RTMP/SRT/NDI streaming, USB-C UVC, 8×PTZ control, pro XLR audio, T-bar, chroma key, 3×PIP, macros & tally.
The AVMatrix Shark S8X is the ultimate compact 8-channel live production switcher for professional multi-camera workflows. Built around a bright 15.6″ 1080p touchscreen, it handles 6×3G-SDI + 2×4K60 HDMI inputs with full multi-view source routing – assign any source to any preview window instantly.
A dedicated AUX input accepts local video playback, UVC webcam, RTSP pull-stream, or optional NDI, making it perfect for remote guests or pre-recorded content. Output simultaneously via 2×HDMI PGM, 4×SDI PGM (all independently configurable), plus HDMI multiview and REF loop-through. Stream via RTMP/SRT/RTSP or optional NDI while recording PGM or ISO to USB drive, SD card, or 2.5″ SATA SSD. USB-C delivers lossless UVC/UAC capture straight to OBS/vMix/Zoom.
Vision mixing includes chroma key, luma key, 3× resizable PIP/POP, DSK, logo overlay, and silky T-bar/Auto/Cut transitions. Professional balanced XLR audio (48V phantom) with embedded + line inputs and full mixing. Control up to 8 PTZ cameras (VISCA/IP, Pelco) with speed, presets, WB, and focus. Record and edit complex macro scripts, plus GPIO tally for on-air lights.
Rugged aluminum chassis, single 12-19V power, and optional V-mount plate make the Shark S8X the ideal flypack for houses of worship, corporate events, education, esports, and mobile production.
Key Features
- 8-Channel Switching – 6×3G-SDI + 2×HDMI 2.0 (4K60) + AUX (playback/UVC/RTSP/NDI)
- Flexible Multi-View – Freely route any source to any preview window
- Outputs – 2×HDMI PGM + 4×SDI PGM + HDMI multiview + REF loop-through
- Streaming – RTMP/SRT/RTSP + optional NDI
- Recording – USB drive / SD card / 2.5″ SATA SSD
- USB-C UVC – Lossless plug-and-play capture to laptop
- Advanced Keying – Chroma/luma key, 3×PIP/POP, DSK, logo overlay
- Pro Audio – 2×XLR balanced (48V phantom), embedded + line inputs, XLR + 3.5mm monitoring
- 8×PTZ Control – VISCA-over-IP / Pelco, presets, speed, WB, focus
- T-Bar + Macros – Manual transitions + fully editable macro scripts
- Tally – GPIO port
