RGBlink Mini ISO

RGBlink Mini ISO

SKU: RGMINIISO

10-Channel All-in-One Switcher

The Mini-ISO is a versatile and powerful device equipped with a wide range of professional features. It offers four 4K HDMI inputs and four SDI inputs, allowing it to process signals from various devices such as PCs, laptops, cameras and other sources. This makes the Mini-ISO ideal for a wide range of applications, from live broadcasts to the production of high-quality video.

For audio processing, the RGBlink Mini-ISO supports both line and microphone levels, allowing for flexible use in a variety of scenarios. Two HDMI outputs offer the possibility of displaying multi-view previews, programme outputs or test images, so that the user always has an overview of all important video sources. In addition, a USB output ensures that the Mini-ISO supports the YUY2 and MJPEG coding formats widely used in the streaming world. These formats can be recognised by the device as a webcam, making it possible to stream in real time to platforms such as Facebook, YouTube or Zoom.

The mini-ISO is equipped with a 3.5-inch TFT touchscreen, which not only enables intuitive menu navigation, but also provides a clear display of the video sources. Equipped with a wide range of functions, the mini-ISO offers dynamic output control, a multi-view preview, picture-in-picture function, chroma key, luma key, various transition effects and integrated PTZ camera control. These extensive options offer the user maximum flexibility and control during video production. For even more user-friendly operation, the Mini-ISO is compatible with Windows and macOS desktop operating systems. In addition, iOS and Android mobile devices can be used to control the device, allowing even more flexible handling. Particularly noteworthy is the support of TAO cloud control, which allows the device to be controlled remotely. In addition, the Mini-ISO can stream simultaneously to up to four live streaming platforms via RTMP(S), making it an ideal tool for professional live broadcasts and event productions. With its wide range of functions and operational flexibility, the mini-ISO is an indispensable tool for anyone working in the field of video and live stream production.

Features

• USB 2.0 one-key recording (exFAT/FAT32) with up to 16Mbps bit rate
• 3.5-inch TFT touchscreen for menu operation, signal preview and status display
• USB output supports YUY2/MJPEG, recognisable as a webcam for streaming
• 4 HDMI 2.0 inputs (up to 4K@60), HDCP 1.4, RTMP(S) streaming on up to 4 platforms
• 4 SDI inputs for signals from PC, camera etc., with PTZ presets and one-key recall
• 2 HDMI 1.3 outputs for multi-view, programme output or test patterns
• PTZ control via 5-direction joystick, supports IP VISCA protocol
• 4-channel HDMI/SDI mix with 2-channel external audio, chroma key (green/blue)
• AUTO and WIPE switch mode, supports Luma Key
• 15 transition effects, TAO cloud control, compatible with mobile devices and desktop
