MID49 Gimbal Bottom ARCA Adapter (DJI Ronin 2)

MID49 Baseline 15mm LW (Sony FX9, FS7, FS7mkII / Canon C100mkII, C300mkII, C100, C300, C500 Baseplate) SKU: M49-BSL-LW0-AC7 Baseline 15mm LW (Sony FX9, FS7, FS7mkII / Canon C100mkII, C300mkII, C100, C300, C500 Baseplate) is a baseplate that holds 15mm lightweight rods at the correct distance from the center of the lens on the listed cameras. ARRI dovetail slot on the bottom attaches to the included Baseline ARRI Dovetail or other ARRI standard dovetails using a top-load locking mechanism. Loosen the thumbscrew and push the silver button on the operator's side to release the baseplate from the ARRI dovetail. To reattach, drop down and listen for the pop to know it has engaged. Adjust the position on the ARRI dovetail, then lock the ratcheting thumbscrew. Baseline ARRI Dovetail is the included lower ARRI mounting plate which can attach to tripod plates using 1/4-20 or 3/8-16 screws or ARRI standard bridgeplates with centered or offset screw spacing. ARCA dovetail slot on top holds the included ARCA Dovetail and can be top-loaded, or installed from the back by sliding in. When sliding in from the back, a safety pin will engage with a pop when properly installed. Adjust the position, then lock the ratcheting thumbscrew. Top-loading can be achieved by loosening the thumbscrew, pulling out on the ratcheting knob, and turning the thumbscrew until ARCA clamp has opened fully. Reverse the process to tighten. Center screw slot on ARCA Dovetail accepts 1/4-20 and 3/8-16 mounting screws, and a vertical rod hole clamps included 1/4-20 lens support posts for adaptors like Metabones, etc. Rod Bracket (15mm LW)(sold separately) can be attached to the back of the baseplate for rear 15mm LW rod support. Individual components of this kit are also available Baseline Core 15mm LW (0mm Platform Height)Baseline ARCA Dovetail (7.5mm Height)Baseline ARRI DovetailTechnical dataProduct Weight: 322gProduct Dimensions (WxLxH): 123 x 140 x 30mm

MID49 Baseline 15mm LW For Canon C400, C300 MK III, C500 MK II, C200, C200B, C700 / Blackmagic Pocket 6K / Kinefinity MAVO Mark 2 BaseplateSKU: M49-BSL-LW13-AC7 Baseline 15mm LW for Canon C400, C300 MK III, C500 MKII, C200, C200B, C700 / Blackmagic Pocket 6K / Kinefinity MAVO Mark 2 is a baseplate that holds 15mm lightweight rods at the correct distance from the center of the lens on the listed cameras. ARRI dovetail slot on the bottom attaches to the included Baseline ARRI Dovetail or other ARRI standard dovetails using a top-load locking mechanism. Loosen the thumbscrew and push the silver button on the operator's side to release the baseplate from the ARRI dovetail. To reattach, drop down and listen for the pop to know it has engaged. Adjust the position on the ARRI dovetail, then lock the ratcheting thumbscrew.Baseline ARRI Dovetail is the included lower ARRI mounting plate which can attach to tripod plates using 1/4-20 or 3/8-16 screws or ARRI standard bridgeplates with centered or offset screw spacing. ARCA dovetail slot on top holds the included ARCA Dovetail and can be top-loaded, or installed from the back by sliding in. When sliding in from the back, a safety pin will engage with a pop when properly installed. Adjust the position, then lock the ratcheting thumbscrew. Top-loading can be achieved by loosening the thumbscrew, pulling out on the ratcheting knob, and turning the thumbscrew until ARCA clamp has opened fully. Reverse the process to tighten.Center screw slot on ARCA Dovetail accepts 1/4-20 and 3/8-16 mounting screws, and a vertical rod hole clamps included 1/4-20 lens support posts for adaptors like Metabones, etc.Rod Bracket 15mm LW (sold separately) can be attached to the back of the baseplate for rear 15mm LW rod support.Individual components of this kit are also availableBaseline Core 15mm LW (13mm Platform Height)Baseline ARCA Dovetail (7.5mm Height)Baseline ARRI Dovetail

Baseline 15mm LW (Blackmagic PYXIS) SKU: M49-BSL-LW13-AC10 Baseline 15mm LW (Blackmagic PYXIS) is a baseplate that holds 15mm lightweight rods at the correct distance from the center of the lens on the listed cameras. ARRI dovetail slot on the bottom attaches to the included Baseline ARRI Dovetail or other ARRI standard dovetails using a top-load locking mechanism. Loosen the thumbscrew and push the silver button on the operator's side to release the baseplate from the ARRI dovetail. To reattach, drop down and listen for the pop to know it has engaged. Adjust the position on the ARRI dovetail, then lock the ratcheting thumbscrew.Baseline ARRI Dovetail is the included lower ARRI mounting plate which can attach to tripod plates using 1/4-20 or 3/8-16 screws or ARRI standard bridgeplates with centered or offset screw spacing. ARCA dovetail slot on top holds the included ARCA Dovetail and can be top-loaded, or installed from the back by sliding in. When sliding in from the back, a safety pin will engage with a pop when properly installed. Adjust the position, then lock the ratcheting thumbscrew. Top-loading can be achieved by loosening the thumbscrew, pulling out on the ratcheting knob, and turning the thumbscrew until ARCA clamp has opened fully. Reverse the process to tighten.Center screw slot on ARCA Dovetail accepts 1/4-20 and 3/8-16 mounting screws, and a vertical rod hole clamps included 1/4-20 lens support posts for adaptors like Metabones, etc. Rod Bracket (15mm LW)(sold separately) can be attached to the back of the baseplate for rear 15mm LW rod support.Weight: 346gDimensions (WxLxH): 123 x 140 x 45mm Individual components of this kit are also availableBaseline Core 15mm LW (13mm Platform Height)Baseline ARRI Dovetail

MID49 Baseline 15mm LW (RED KOMODO, KOMODO-X / Blackmagic Pocket 4K / FREEFLY Ember S5K Baseplate) SKU: M49-BSL-LW23-AC14 Baseline 15mm LW (RED KOMODO, KOMODO-X / Blackmagic Pocket 4K / FREEFLY Ember S5K Baseplate) is a baseplate that holds 15mm lightweight rods at the correct distance from the center of the lens. ARRI dovetail slot on the bottom attaches to the included Baseline ARRI Dovetail or other ARRI standard dovetails using a top-load locking mechanism. Loosen the thumbscrew and push the silver button on the operator's side to release the baseplate from the ARRI dovetail. To reattach, drop down and listen for the pop to know it has engaged. Adjust the position on the ARRI dovetail, then lock the ratcheting thumbscrew. Baseline ARRI Dovetail is the included lower ARRI mounting plate which can attach to tripod plates using 1/4-20 or 3/8-16 screws or ARRI standard bridgeplates with centered or offset screw spacing. ARCA dovetail slot on top holds the included ARCA Dovetail and can be top-loaded, or installed from the back by sliding in. When sliding in from the back, a safety pin will engage with a pop when properly installed. Adjust the position, then lock the ratcheting thumbscrew. Top-loading can be achieved by loosening the thumbscrew, pulling out on the ratcheting knob, and turning the thumbscrew until ARCA clamp has opened fully. Reverse the process to tighten. Center screw slot on ARCA Dovetail accepts 1/4-20 and 3/8-16 mounting screws, and a vertical rod hole clamps included 1/4-20 lens support posts for adaptors like Metabones, etc. Rod Bracket (15mm LW) (sold separately) can be attached to the back of the baseplate for rear 15mm LW rod support. Individual components of this kit are also available: Baseline Core 15mm LW (23mm Platform Height)Baseline ARCA Dovetail (14.5mm Height)Baseline ARRI Dovetail Technical data Product Weight: 350gProduct Dimensions (WxLxH): 123 x 140 x 58mm

MID49 Baseline 15mm LW (Sony FS5, Panasonic EVA1, VariCam LT, VariCam 35 Baseplate) SKU: M49-BSL-LW13-AC12 Baseline 15mm LW (Sony FS5, Panasonic EVA1, VariCam LT, VariCam 35 Baseplate) is a baseplate that holds 15mm lightweight rods at the correct distance from the center of the lens on the listed cameras. ARRI dovetail slot on the bottom attaches to the included Baseline ARRI Dovetail or other ARRI standard dovetails using a top-load locking mechanism. Loosen the thumbscrew and push the silver button on the operator's side to release the baseplate from the ARRI dovetail. To reattach, drop down and listen for the pop to know it has engaged. Adjust the position on the ARRI dovetail, then lock the ratcheting thumbscrew. Baseline ARRI Dovetail is the included lower ARRI mounting plate which can attach to tripod plates using 1/4-20 or 3/8-16 screws or ARRI standard bridgeplates with centered or offset screw spacing. ARCA dovetail slot on top holds the included ARCA Dovetail and can be top-loaded, or installed from the back by sliding in. When sliding in from the back, a safety pin will engage with a pop when properly installed. Adjust the position, then lock the ratcheting thumbscrew. Top-loading can be achieved by loosening the thumbscrew, pulling out on the ratcheting knob, and turning the thumbscrew until ARCA clamp has opened fully. Reverse the process to tighten. Center screw slot on ARCA Dovetail accepts 1/4-20 and 3/8-16 mounting screws, and a vertical rod hole clamps included 1/4-20 lens support posts for adaptors like Metabones, etc. Rod Bracket (15mm LW)(sold separately) can be attached to the back of the baseplate for rear 15mm LW rod support. Individual components of this kit are also available: Baseline Core 15mm LW (13mm Platform Height)Baseline ARCA Dovetail (12mm Height)Baseline ARRI Dovetail Technical data Product Weight: 346gProduct Dimensions (WxLxH): 123 x 140 x 45mm

MID49 Baseline 15mm LW (RED V-Raptor Baseplate) SKU: M49-BSL-LW23-AC7 Baseline 15mm LW (RED V-Raptor Baseplate) is a baseplate that holds 15mm lightweight rods at the correct distance from the center of the lens.ARRI dovetail slot on the bottom attaches to the included Baseline ARRI Dovetail or other ARRI standard dovetails using a top-load locking mechanism. Loosen the thumbscrew and push the silver button on the operator's side to release the baseplate from the ARRI dovetail. To reattach, drop down and listen for the pop to know it has engaged. Adjust the position on the ARRI dovetail, then lock the ratcheting thumbscrew. Baseline ARRI Dovetail is the included lower ARRI mounting plate which can attach to tripod plates using 1/4-20 or 3/8-16 screws or ARRI standard bridgeplates with centered or offset screw spacing. ARCA dovetail slot on top holds the included ARCA Dovetail and can be top-loaded, or installed from the back by sliding in. When sliding in from the back, a safety pin will engage with a pop when properly installed. Adjust the position, then lock the ratcheting thumbscrew. Top-loading can be achieved by loosening the thumbscrew, pulling out on the ratcheting knob, and turning the thumbscrew until ARCA clamp has opened fully. Reverse the process to tighten. Center screw slot on ARCA Dovetail accepts 1/4-20 and 3/8-16 mounting screws, and a vertical rod hole clamps included 1/4-20 lens support posts for adaptors like Metabones, etc. Rod Bracket (15mm LW) (sold separately) can be attached to the back of the baseplate for rear 15mm LW rod support. Individual components of this kit are also available: Baseline Core 15mm LW (23mm Platform Height)Baseline ARCA Dovetail (7.5mm Height)Baseline ARRI Dovetail Technical data Product Weight: 330gProduct Dimensions (WxLxH): 123 x 140 x 51mm

MID49 Baseline 15mm LW (Sony Burano, FX6, Venice, Venice 2, Rialto, F55, F5 / Blackmagic URSA Mini, Mini Pro, Mini Pro 12K Baseplate)SKU: M49-BSL-LW0-AC12 Baseline 15mm LW (Sony FX6, Venice, Venice 2, Rialto, F55, F5 / Blackmagic URSA Mini, Mini Pro, Mini Pro 12K Baseplate) is a baseplate that holds 15mm lightweight rods at the correct distance from the center of the lens on the listed cameras. ARRI dovetail slot on the bottom attaches to the included Baseline ARRI Dovetail or other ARRI standard dovetails using a top-load locking mechanism. Loosen the thumbscrew and push the silver button on the operator's side to release the baseplate from the ARRI dovetail. To reattach, drop down and listen for the pop to know it has engaged. Adjust the position on the ARRI dovetail, then lock the ratcheting thumbscrew. Baseline ARRI Dovetail is the included lower ARRI mounting plate which can attach to tripod plates using 1/4-20 or 3/8-16 screws or ARRI standard bridgeplates with centered or offset screw spacing. ARCA dovetail slot on top holds the included ARCA Dovetail and can be top-loaded, or installed from the back by sliding in. When sliding in from the back, a safety pin will engage with a pop when properly installed. Adjust the position, then lock the ratcheting thumbscrew. Top-loading can be achieved by loosening the thumbscrew, pulling out on the ratcheting knob, and turning the thumbscrew until ARCA clamp has opened fully. Reverse the process to tighten. Center screw slot on ARCA Dovetail accepts 1/4-20 and 3/8-16 mounting screws, and a vertical rod hole clamps included 1/4-20 lens support posts for adaptors like Metabones, etc. Individual components of this kit are also available: Baseline Core 15mm LW (0mm Platform Height)Baseline ARCA Dovetail (12mm Height)Baseline ARRI DovetailTechnical dataProduct Weight: 334gProduct Dimensions (WxLxH): 123 x 140 x 33mm

MID49 Upper Cage for Canon C70 SKU: M49-CAG-CAN-C70 Upper Cage for Canon C70 is a form-fitting cage with 1/4-20, 3/8-16 with ARRI accessory pins, and M4x20mm ARRI-spaced threaded holes in several places. Included 15mm accessory rods provide threaded holes, a shoe mount, and special recess for the Audio Breakout AB-4 (Canon C70) which is available as an add-on, and converts the camera's two mini XLRs to standard, full-size XLRs. HDMI protector clamps cables securely, and front lens support mount attaches to 3rd party lens adapters like Metabones, etc. Top ARCA Swiss dovetail slot accepts products like our ARCA Top Handle or ARCA Top Plate which are sold separately. Lower ARCA Swiss dovetail attaches to our Baseline 15mm Baseplate to provide rods at the correct lens height and is also available separately.

MID49 Upper Cage for Canon C80SKU: M49-CAG-CAN-C80 Upper Cage for Canon C80 is a form-fitting cage with 1/4-20, 3/8-16 with ARRI accessory pins, and M4x20mm ARRI-spaced threaded holes in several places. In the center channel, a replica of the Canon striped rosette allows the C80's original handle to be attached. The included top accessory rod holds a combination hot shoe, ARRI 3/8-16, M4x20, and the Canon mic hole pattern for attaching the C80's original microphone shock mount.A special 1/4-20 recess at the end of the rod holds the Audio Breakout AB-4 (Canon C70/C80) which is available as an optional add-on, and converts the camera's two mini XLRs to standard, full-size XLRs. HDMI protector clamps cables securely, and front lens support mount attaches to 3rd party lens adapters like Metabones, etc.Top ARCA Swiss dovetail slot accepts products like our ARCA Top Handle or ARCA Top Plate which are sold separately. Lower ARCA Swiss dovetail attaches to our Baseline 15mm Baseplate to provide rods at the correct lens height and is also available separately.Weight: 438gDimensions (WxLxH): 438 x 132x 162mm

MID49 Upper Cage for FUJIFILM GFX100 II SKU: M49-CAG-FUJ-G100ii Upper Cage for FUJIFILM GFX100 II is a form-fitting cage with 1/4-20, 3/8-16 with ARRI accessory pins, and M4x20mm ARRI-spaced threaded holes in several places. Included 15mm accessory rods provide threaded holes, a shoe mount, and special recess for the Audio Breakout AB-3 which is available as an add-on, and converts the camera's two mini XLRs to two standard, full-size XLRs.HDMI and USB protector clamps cables securely, and front lens support mount attaches to 3rd party lens adapters like Metabones, etc.Top ARCA Swiss dovetail slot accepts products like our ARCA Top Handle or ARCA Top Plate which are sold separately.Lower ARCA Swiss dovetail attaches to our Baseline 15mm Baseplate to provide rods at the correct lens height and is also available separately.

MID49 Upper Cage for Blackmagic Pocket 6K (Full Frame, Pro, G2)SKU: M49-CAG-BMD-P6K Upper Cage for Blackmagic Pocket 6K (Full Frame, Pro, G2) is a form-fitting cage with 1/4-20, 3/8-16 with ARRI accessory pins, and M4x20mm ARRI-spaced threaded holes in several places. Included 15mm accessory rods provide threaded holes, a shoe mount, and special recess for the Audio Breakout AB-6 (Blackmagic Pocket 6K), which is available as an add-on, and converts the camera's two mini XLRs to two standard, full-size XLRs. HDMI and USB protector clamps cables securely, and front lens support mount attaches to 3rd party lens adapters like Metabones, etc. Top ARCA Swiss dovetail slot accepts products like our ARCA Top Handle or ARCA Top Plate which are sold separately. Lower ARCA Swiss dovetail attaches to our Baseline 15mm Baseplate to provide rods at the correct lens height and is also available separately.
