Marshall CV355-27X-ND3

Marshall CV355-27X-IPThe CV355-27X-IP 27X optical zoom IP (HEVC/SRT) camera utilizes a professional grade 8.5-megapixel sensor to capture crisp HD video up to 1920x1080 at 60fps with support for all HD formats. Marshall's straight forward design and ease of use make this camera a valuable tool in a wide variety of broadcast and professional A/V applications. The 27X optical zoom block offers an extensive zoom range from 5.56mm to 150mm starting at 60° all the way out to 3.2° horizontal angle-of-view for maintaining image crispness from ultra-wide to long telephoto shots.SRT stands for Secure Reliable Transport. SRT is an open-source video transport protocol and technology stack that optimizes video streaming performance across unpredictable networks. With secure streams and simplified firewall traversal, SRT delivers the best quality video over the worst networks.The CV355-27X-IP operates with exceptional low-light sensitivity, ensuring a clear picture in variable and challenging lighting conditions, including live events, houses of worship, indoor or outdoor sporting events, and other dynamic lighting environments.One cable to camera provides up to HD video, audio, control, and power (PoE) over one cable with IP (HEVC) and HDMI simultaneous outputs with stereo audio embedding. Features8.5 Megapixel (1/2.5") HD sensor27X Optical Zoom (5.5~150mm) - 60° AOVSupports:1092x1080p and 720p 60/59.94/50/30/29.97/25 fps, 1920x1080i 60/59.94/50 fpsIP formats: SRT, DHCP, DNS, HTTP, HTTPS, IPv4, NTP, RTSP, RTCP, RTP, TCP, UDPIP (HEVC/SRT) and HDMI simultaneous outputsEthernet I/O supports video, control, audio and PoE over a single cableRS232 and 3.5mm audio input with passthrough Technical dataSensorSensor Type: IMX317Lens ModuleOptical Zoom: 27xDigital Zoom: 12xAngle of View (H): 60°Vertical Viewing Angle: 35°Diagonal Viewing Angle: 68°Aperture: F1.66~F4.98Focal Length : f=5.56mm~150.29mmFocus Distance: Wide: 1m ~ ∞ / Tele: 1.5m ~ ∞Field of View: Wide Horizontal viewing angle=60° (+/-5%) / Tele Horizontal viewing angle=3.2° (+/-5%)Minimum Environmental Illumination: 10 luxMinimum Illumination: 0.1 lux (F1.6, 50IRE, 30fps)Camera SystemStream: Dual Stream (Main/Sub) / WebpageStreaming Protocol: RTSP / RTMP / RTMPS / SRTVideo Compression: HEVC (H.265) / AVC (H.264) / MJPEGAudio Compression: G.711 / AACPreset: 256Preset Speed: NAFocus System: Auto/ One-Push AF / ManualElectronic Shutter: 1/1 to 1/10000 secExposure Control: Auto / Shutter Pri / Iris Pri / ManualGain Control: Auto, ManualBrightness Control: Yes3D NR: YesWDR: YesBacklight Compensation: YesWhite Balance: Auto, Manual R/B GainFlip / Mirror: YesFirmware Update: Operation on WebpageOutput ResolutionHDMI: 1080p: 60 / 59.94 / 50 / 30 / 29.97 / 25 fps3G-SDI: 1080p: 60 / 59.94 / 50 / 30 / 29.97 / 25 fpsStream: PTZ view 1080p: 60 / 59.94 / 50 / 30 / 29.97 / 25 fpsWebpage: PTZ: MJPEG 360pInterfaceLine In: x1 ; 3.5mm phone jackLine Out: x1 ; 3.5mm phone jackAudio Output: HDMI / 3G-SDI / RTSP / RTMP / SRTAudio Type: Stereo, UnbalancedAudio Compression Format: AACHDMI: x1Audio Output: YesHDMI Color Format: RGB / YUV4223G-SDI: x1Audio Output: YesSerial: RS232RS232 In: RS232 In ; Mini-Din x1RS232 Out: RS232 Out ; Mini-Din x1NetworkEthernet RJ45 Port: x1 ; 1GbpsNumber of Clients (connection): RTSP 1080P60 *5Network Protocol: DHCP, DNS, HTTP, HTTPS, IPv4, NTP, RTSP, RTCP, RTP, TCP, UDPNetwork Security: No Critical issuesCamera ControlSerial Control: RS-232 In x1 ; RS-232 Out x1Protocol: VISCABaud Rate: 9600 / 38400NetworkWebpage: HTTP CGI / HTTP API / Onvif Profile S / VISCA over IPGeneralTally Light: Yes ; RedService Button: NAPower Supply: POE ; IEEE 802.3af / DC 12V/3A ; EIAJ Type 4Power Consumption: PoE: ≦ 15W ; DC: ≦ 13WDimensionsDimensions: 187mm (l) x 67mm (w) x 67mm (h)
